Nonstandard Stainless Hinges for Door and Window OEMs
A custom hinge must keep the leaf, frame and pivot working together. Relia reviews stainless lost-wax castings and defined machining around the mounting pattern, opening movement and finish required by your door or window design.
RELIA · PRODUCT AND MANUFACTURING SUPPORT
Define the hinge and included items
Relia's hinge references include custom stainless precision casting and machining, with a 500-piece minimum on one listed item. Relia's scope review links the leaves, pivot and mounting pattern to the complete door/frame relationship. Your team can therefore define the actual running fit, finish and required functional testing before approving the hinge.
| Your requirement | Relia product and service scope |
|---|---|
| Material | Stainless steel, grade to specification |
| Route | Lost-wax casting with defined machining |
| Order reference | 500-piece minimum on one hinge listing |
| Key checks | Pivot fit, leaf relationship, opening range and mounting pattern |
02 · INTERFACES
Match frame and leaf mounting geometry
- Frame relationship
- Provide hole positions, locating faces and handed geometry.
- Finished leaf
- Review mounting and movement against the mating frame.
Keep hole positions, locating faces and handed arrangements on the controlled drawings. The mating frame information helps us review the finished leaf beyond its outside shape.
Technical notes
Separate cast leaf shape from machined pin holes and bearing surfaces. Identify pins, bushes and fasteners included in the order. A 0.2 mm catalogue tolerance reference does not define the running fit between a hinge pin and bore or the door alignment required by your design.
MANUFACTURING ROUTE · FEATURES AND CONTROL
Form the Leaves and Establish the Pivot Alignment
The cast leaf shape needs stock and access for the controlled pin holes and contact surfaces. Relia's machining review establishes the bore relationship and the geometry that sets the pivot axis. Pin, bush and fastener inclusion are defined separately. Deburring and surface finishing must preserve the running clearance and visible finish. A first assembly checks opening range, interference and mounting position; any load or cycle trial uses the agreed door arrangement and acceptance conditions rather than an unexplained durability label.
- Define hinge geometryLeaves, pivot, fixings and opening envelope
- Cast the leaf bodiesStainless shape and finishing allowance
- Machine the pivot featuresAligned bores, contacts and included pins/bushes
- Trial the assemblyMotion, appearance and specified load/cycle checks
04 · MATERIAL
Specify stainless grade and manufacturing condition
- Material requirement
- Specify the stainless grade and supplied condition.
- Manufacturing scope
- Define cast features, machining and surface treatment.
Share the exact grade, cast or machined scope and surface condition your project requires. Any alternative needs review against the intended environment and functional design.
05 · ACCEPTANCE
Approve appearance and function on clear criteria
Check pivot alignment, hole positions, opening clearance and finish. If cycle life or load testing is required, agree the assembly, load, cycles and failure criteria. These conditions provide a meaningful approval basis instead of an unsupported universal durability claim.
06 · REPEAT SUPPLY
Keep similar hinge variants distinct
- Variant identity
- Separate sizes, handed parts and mounting patterns.
- Repeat reference
- Retain accepted samples and their drawing revisions.
Retain separate drawing identities for different sizes, handed parts and mounting patterns. Keep accepted samples and deviations linked to the relevant revision.
07 · ORDER CONTROL
Release a complete hinge-component package
The quotation should identify the material, operations, finish and included parts. Keep required records and unresolved mating inputs visible until the scope is agreed.
Technical notes
Define leaf thickness, hole pattern, pivot axis, opening range and door/frame relationship. Include the intended load and operating environment. The hinge's usable motion depends on the axis position and clearance, not simply on matching the leaf outline.
| Package | Retain |
|---|---|
| Technical | Current leaf and mating drawings |
| Manufacture | Material and finished condition |
| Approval | Required appearance and functional checks |
CONNECTED BUYING GUIDES
Continue with the next project decision
Follow the related component and purchasing guides, or open the catalogue reference to carry this requirement into a specific project enquiry.
RELIA · YOUR NEXT PROJECT
Share the hinge and frame-interface drawings
Send the component models, pivot requirements, material and quantities. Identify variants and required finish or functional checks. We can review the manufacturing and included-component scope with your team.
Start with these project details
- Leaf and frame drawings
- Pivot and movement requirements
- Stainless grade and finish
- Variant quantities and approval checks
